System description

by Masa Bulic

EXCELLENT ENJOYMENT

With extremely low temperatures and a very large heater, heating can offer you nothing but pure pleasure. In fact, the quality of a comfortable life is given the utmost attention. The results are as follows:

– Even and balanced heat emission;
– Even temperature distribution across floor and space;
– Almost ideal temperature profile (warm feet and cool head);
– Selecting the temperature mode for each room separately;
– Acceptability from a landscaping standpoint (no radiator)
– Does not cause noise, odors, dust circulation and unacceptable surface temperatures;
– Good regulatory capabilities;
– Selectable floor, wall or combination installation.

SECURITY

The system operates at a safe 3-48V low electrical voltage. You can rotate or wet the heating strips without consequence. Repair of any damage to the straps is not demanding. Damage can be located under the screed and on the floor coverings. There is no danger of spills.

The values ​​of electromagnetic radiation are significantly below the permissible values. For “better feeling”, at the request of our clients, we do not put heating strips under the bed. So no adverse effects of EM radiation!

HYGIENE

The main difference between “radiator” and underfloor heating is the way heat is transferred to the room. Underfloor heating evenly radiates or radiates heat, and radiators convert it, ie. transmitted by air circulation. In this way, in addition to heat, dust and all biological vegetation that develops on moist soil are transferred into the space. By heating or drying the soil, floor heating greatly prevents the development of these organisms.

So: less dust, less dust mites, less bacteria, less allergies…

Has no adverse effect on the vascular system
The system has a very large heater and a suitable, extremely low temperature or operating temperature. The temperature of the floors in the rooms where we stay longer is close to 26 ° C, which is 10 ° C less than our body temperature.

The low temperature regime completely eliminates the possibility of a negative effect on the vascular system!
For example, if you want to feel the warmth of a floor that is heated to 26 ° C, you must lay one hand on the floor and the other on the wall.

The theory that continuous heating can adversely affect the bloodstream came about at a time when underfloor and “radiator” heating was used by the same boilers with high temperature heating.

Bathrooms

by Masa Bulic

When it comes to heating homes and apartments, the trend that is constantly growing is the installation of underfloor heating.

Residential buildings

by Masa Bulic

The whole system connects to a regular electrical outlet, that is, to a 220-230V supply. Next to it, a box with a converter is mounted on the wall, which turns 220V to 12V .

Assembly

by Masa Bulic

Underfloor heating strips are 3 to 15 cm wide. Unlike cables, these tapes can be punctured without consequence or completely submerged in water. The only important thing is that they are not completely broken!

Instalation

by Masa Bulic

Floor construction:

Heating strips are usually installed under screed or insulated, but can also be placed on screed or under floor coverings. The floor level increases by only 0.4 mm. While it may sound weird, we have also placed the strips on existing flooring (mobile version).

The only condition is that they are covered by something because of the visual effect. You can use everything: warm flooring, laminate flooring, rubber, carpet, gypsum boards, artificial turf, etc. Of course, you can also use ceramic or stone, if the existing floors allow. Because of this, the heating strips allow for dry and wet screeds and all kinds of floor coverings. You will be warmed wherever you place them.

Wall construction:

In the case of wall mounting, the mounting options are unlimited. The strips can be placed below or above the plaster. It is only important that there is thermal insulation for the heaters (outside or inside the wall), otherwise heat will be lost.

When adjusting to a wall, we usually install a layer of insulation, fixing the tape heaters to it (up to 180-200 cm) and covering them with all plasterboard. If the walls are too guilty of such intervention, we align them with Al-profiles. In any case, the procedure is not too demanding.

With a little effort, you can get the equivalent of warming up on the floor.
Ceiling design is also possible.

Electronics:

It is usually mounted in the wall, so that only the cover of electrical circuits and thermostats is visible after installation, but different solutions are possible.

Housing dimensions are 22x35x10 or 35x35x10.

There is no need to mount an electronic assembly or assemblies in a heated room. Users usually choose to install in the hallway. In other rooms only thermostats remain.
